Product introduction:

The inverter power supply module adopts the latest power technology and digital DSP control, it is designed for new energy. The front stage adopts industry-leading three-phase active power factor correction (APFC) technology, and the latter stage adopts three-level full-bridge resonant soft switching technology. The input voltage range is wide, the total harmonic current is less than 3%, and the input power factor is up to 0.99. Efficient, high power density, high reliability. It adopts forced air cooling to dissipate heat, which occupies a small space and easy to assemble!

Features:

◆ Ultra-wide output voltage range: 200V~500Vdc;

◆ DC/DC conversion adopts full-bridge phase-shift soft switching technology;

◆ Adopt the world's leading active power factor correction (APFC) technology, input current total harmonic distortion THDI≤3%;

◆ High power output: 15KW, high power factor output: ≥ 0.99 full load;

◆ The DC output has an anti-backflow device to prevent instantaneous high current at the output of the charger when the battery pack is connected;

◆ Input and output adopt full isolation technology;

◆ Perfect protection and warning function, noise voltage warning, short circuit protection, fault warning;

◆ Support hot swap function;

◆ Fully digital DSP/DSP dual-core processor, supporting CAN2.0 bus communication function;

◆ Support voltage regulation, current limiting and current sharing functions;

◆ Support input over/under voltage protection, input over current protection (use with air switch), input three-phase unbalance protection;

◆ Support output over voltage protection, output over current protection, output short circuit protection, phase loss protection, over temperature protection, total harmonic distortion;

◆ The voltage rating, insulation rating, and EMC are in line with my country's relevant technical standards for electric vehicle chargers
